coM.satISDNBasicUMTS The connections and significance of the LED’s are labelled to prevent errors. Before starting up the device, the SIM cards must be inserted into the provided holders. Two 3V SIM cards are required for full channel availability, but usage with one SIM card is possible. To insert the SIM cards in the device, first push in the round yellow button next to the cardholder with a blunt, thin tool and then remove the cardholder. The SIM card is then placed in the cardholder and inserted into the card reader together with its holder. The contact area of the cardholder must be facing the rear of the device. Attention: When pushing in the card, ensure that it does not fall out of the cardholder and that the card is correctly inserted in the cardholder guides. The device requires 3V SIM cards for operation! 3.1 Starting up the device The SIM cards should be inserted into their reader slot first. Then the necessary cables are connected: Connection to the TC system as NT or TE, a connection to the PC's USB port on which the coMsat.exe application is installed, and finally the antenna cables. Note 1: The GSM/UMTS modules used in the coM.satISDNBasicUMTS for communication via the GSM/UMTS network operate with an internal voltage of 3V. Therefore, for proper operation, SIM cards that can still operate with a working voltage of 3V must be used. All new SIM cards usually fulfil this requirement. If older cards (designed for a voltage of 5V) are used, the device possibly cannot log into the network - despite input of the correct PIN - because the SIMs cannot operate correctly at a voltage they weren't designed for. Note 2: When looking at the front of the device, the left-hand SIM card is assigned to channel 1 and the right-hand card to channel 2. Once it has been installed, the device can be switched on by inserting the power jack. This is indicated by the green LED which is labelled “Power“. All the relevant parameters in the device are deleted in the factory before delivering the coM.satISDNBasicUMTS, so that it must be set for the individual installation. Therefore, when installing the TA for the first time, it must be configured using the coMsat.exe application. To do this, a USB data link must be established between the coM.satISDNBasicUMTS and the PC on which the application is installed. created: page: file: 11/04/07 16 coMsatISDNBasic Manual UMTS.doc Note Protection Mark according to DIN 34!

Drivers

coM.satISDNBasicUMTS 3.2 Installation of the coMsat.exe application The coMsat.exe Windows® application is used to configure the coM.satISDNBasicUMTS. It is copied into a suitable directory on a PC together with two text files: Figure 5: coMsat.exe Installation The coMsat.exe application can now be executed from this directory or via a symbolic link that can be created manually e.g. on the desktop. A free USB port on the PC is required for operation with the coM.satISDNBasicUMTS. coMsat.exe needs a virtual COM port to access the ISDNBasicUMTS. To install it, the current user must have administrator rights and the contents of the FTDI folder must be stored in a suitable directory. If the ISDNBasicUMTS is attached to the PC for the first time, the Windows® hardware assistant automatically reports a new device. It asks for the installation files contained in the FTDI folder. After installation is completed, a new virtual COM port has been added, e.g. COM3. This port must be used in coMsat.exe. The virtual device driver is supplied by Future Technology Devices International Ltd., the manufacturer of the USB/RS 232 converter used in the ISDNBasicUMTS. If another driver is required, it can be obtained from www.ftdichip.com. The driver for FT232BM must be used. The following four files in the FDTI distribution must be replaced by those shipped with the ISDNBasicUMTS: FTDIBUS.INF FTDIPORT.INF FTDIUN2K.INI FTDIUNIN.INI created: page: file: 11/04/07 17 coMsatISDNBasic Manual UMTS.doc Note Protection Mark according to DIN 34!

There are two ISDN implementations. Basic Rate Interface (BRI), also called basic rate access (BRA) — consists of two B channels, each with bandwidth of 64 kbit/s, and one D channel with a bandwidth of 16 kbit/s. Together these three channels can be designated as 2B+D.
